產品介紹：

■ 1.執行標準 Executive standard （Q/321023KLA33）

 ■ 2.適用范圍 Application range 本產品適用于交流額定電壓35kv及以下的電力輸配電線路，特別適用于地鐵、隧道、電站、石油化工、高層建筑等對電纜阻燃性能有高要求的重要場合。 This product is suitable for power distribution circuit of AC rated voltage up to and including 35KV ,especially,applicable for important locations that requires cable with high anti-flaming performance such as underground railway,channel,power station.petrochemical,tall buidings,etc..

■ 3.產品結構圖 Diagram of product structure 1

 1-導體 2-絕緣 3-隔火層 4-包帶 2 5-內護 6-鎧裝 7-外護套 3 1-Condcutor 2-Insulation 3-Fire stop sealer 4-Bingding 4 5-Inner sheath 6-Armor 7-Outer sheath 5 6 7

 ■ 4.型號、名稱 Type、Designation

產品型號名稱見表1 Refer to table 1 for product model and name 型號Model 名稱 Name

銅芯 Copper Conductor

鋁芯 Aluminum conductor GZR-W GZR-VLV

聚氯乙烯絕緣聚氯乙烯護套隔火層阻燃電力電纜 PVC insulated and sheathed anti-flaming power cable with fire stop sealer anti-flaming power cable with fire stop sealer GZR-YJV GZR-YJLV

交聯聚乙烯絕緣聚氯乙烯護套隔火層阻燃電力電纜 XLPE insulated PVC sheathed anti-flaming power cable with fire stop sealer GZR-VV22 GZR-VLV22

聚氯乙烯絕緣鋼帶鎧裝聚氯乙烯護套隔火層阻燃電力電纜 PVC insulated steel tape armored and sheathed anti-flaming power cable with fire stop sealer GZR-YJV22 GZR-YJLV22

交聯聚乙烯絕緣鋼帶鎧裝聚氯乙烯護套隔火層阻燃電力電纜 XLPE insulated steel tape armored PVC sheathed anti-flaming power cable with fire stop sealer

產品規格見表2 Refer to table 2 for product specification

型號 Model 芯數 Core 額定電壓KV Rated voltage KV 0.6/1 1.8/3 3.6/6、6/6 8.7/10 21/35、26/35

標稱截面MM2 Nominal cross sectional mm2 GZR-VV GZR-VLV 1 2.5-300 - - - - GZR-YJV GZR-YJLV 2.5-300 10-300 25-300 25-300 50-300 GZR-VV GZR-VLV GZR-YJV GZR-YJLV GZR-VV22 GZR-YJLV GZR-YJV22 GZR-YLLV22 2 2.5-185 - - - - GZR-VV GZR-VLV 3 2.5-300 - - - - GZR-YJV GZR-YJLV 2.5-300 10-300 25-300 25-300 - GZR-VV22 GZR-VLV22 GZR-YJV22 GZR-YJLV22 4-300 - - - - GZR-VV GZR-VLV GZR-YJV GZR-YJLV GZR-VV22 GZR-VLV22 GZR-YJV22 GZR-YJLV22 4 4-185 - - - - GZR-VV GZR-VLV GZR-YJV GZR-YJLV 3+1 4-300 - - - - GZR-VV22 GZR-VLV22 GZR-YJV22 GZR-YJLV22 4-185 - - - - GZR-VV GZR-VLV GZR-YJV GZR-YJLV GZR-VV22 GZR-VLV22 GZR-YJV22 GZR-YJLV22 5 3+2 4+1 4-185 - - - -
